FLUOstar Omega

Filter-basierter multi-mode Reader der Omega Serie

Der FLUOstar^® Omega ist ein multi-mode Microplate Reader mit drei Detektionsmethoden. Der Reader nutzt ein ultraschnelles UV/vis-Spektrometer für Absorption und hochsensible optische Filter für alle weiteren Detektionsmethoden. Der FLUOstar Omega ist der ideale Microplate Reader für Anwendungen im Life-Science-Bereich.

Broschüre herunterladen
Informationen anfordern

Detektionsmethoden

Absorbance
Fluorescence intensity (incl. FRET)
Luminescence (incl. BRET)
Fluorescence polarization
AlphaScreen
Nephelometry
Time-resolved fluorescence
TR-FRET

Produktdetails Bewertungen Application Notes Publikationen Technische Spezifikationen Zubehör Geräte vergleichen

FLUOstar Omega

Der FLUOstar Omega ist ein vielseitiger multi-mode Microplate Reader mit sechs Detektionsmethoden: Fluoreszenz Intensität (inklusive FRET), Lumineszenz (inklusive BRET), UV/Vis Absorption, zeitaufgelöste Fluoreszenz, TR-FRET und AlphaScreen^®/AlphaLISA^®.

Eigenschaften

Absorptionsmessungen mit höchster Geschwindigkeit
Messungen in bis zu 384-Well Mikroplatten
Top- und Bottom-Reading
Inkubation bis zu 45 °C oder 65 °C
Benutzerdefinierte Schüttelfunktionen
Well-Scanning mit bis zu 900 Messpunkten pro Well
Präzise Injektoren mit simultaner Reagenzinjektion und Messung
Messung kleinster Volumina

Referenzen

Microplate Reader Technologien

Gas Vent

BMG LABTECH offers two forms of gas control on its microplate readers. The Atmospheric Control Unit (ACU) for the CLARIOstar is a unique microprocessor-controlled unit that independently regulates both CO2 and O2 inside the microplate reader. Alternatively, the Gas Vent is a positive pressure gas purge through which the internal atmosphere of the microplate reader can be replaced.

Incubation and shaking

Shaking and incubation allow users to mix the well content and easily run measurements at elevated temperatures. The incubator controls the air temperature in the measurement chamber from room temperature up to 45°C, 60°C or 65°C. BMG LABTECH microplate readers are equipped with orbital, double-orbital or linear shaking with definable intensity, duration and direction of motion. These features are available on all BMG LABTECH plate readers.

Path length correction

Absorbance measurements such as DNA quantification or protein determination detected in a microplate reader are frequently compared and/or normalized to results from a 1 cm path length cuvette. All BMG LABTECH microplate readers have the ability to perform a 1 cm path length correction thanks to an internal fitting algorithm. Using this correction, data normalization to 1 cm path is given with only one mouse click.

Reagent injectors

Many of today's most popular assays such as enzyme kinetics, calcium flux, and dual luciferase require the ability to monitor a signal during and after the addition of a reagent. All BMG LABTECH readers, with the exception of the SPECTROstar Nano, can be equipped with up to two reagent injectors. Injectors enable reagent delivery to any plate format from 6 to 384 wells.

UV/vis spectrometer

BMG LABTECH was the first and is the only microplate reader manufacturer to equip its instruments with a UV/vis spectrometer for absorbance measurements. Similar to a monochromator, but much faster, the spectrometer will capture full-absorbance spectra from 220 to 1000 nm at a resolution of 1 nm in less than one second/well. Alternatively, up to eight discrete wavelengths can be collected at the same time.

Well-scanning

For non-homogeneous samples such as for cell-based assays, where the sample distribution is uneven across the well, a single reading in the centre of the well is inadequate. To overcome this problem, all BMG LABTECH readers come with an advanced Well Scanning feature that can take multiple measurements in each well with a resolution of up to 900 points/well. Alternatively, in spiral or orbital averaging mode, the reader takes several measurements for each well on a defined spiral or orbit and calculates an average.

Xenon Flash lamps

Microplate readers require a light source to provide the incident of light directed at the sample.

Comparing site speciﬁc phospho-tau in normal and Alzheimer’s disease brains

Are you looking for new tools for Alzheimer's diagnosis? Read here how phospho-tau modifications can be detected with ELISAs and potentially used as biomarkers.

Differential activation of G proteins by synthetic cannabinoid receptor agonists, utilizing the CAMYEL BRET biosensor

Synthetic cannabinoids become increasingly associated to drug misuse. Read how the CAMYEL BRET biosensor can be used to study the associated signaling pathways in plate readers.

Testing novel bacteriophages for antibacterial properties with a crystal violet biofilm quantification assay

Antibiotic resistance in bacteria is a growing threat to human health. Read this App note to learn how bacteriophage efficacy can be evaluated on microplate readers.

Real-Time Cell Motility Tracking Increases the Throughput of Scratch Wound Assays

Interested in the real-time monitoring of wound healing without the use of a microscope? Read here how bioluminescent visualization of cells enables the analysis with microplate readers.

NextGenPCR™ evaluated with a fluorescence microplate reader accelerates testing for SARS-CoV-2 viral RNA

Viability assays: a comparison of luminescence-, fluorescence-, and absorbance-based assays to determine viable cell counts

Not sure which cell viability assay is the best choice for you? This AppNote compares different kits based on absorbance, fluorescence and luminescence readouts.

Alle Application Notes anzeigen
