SPECTROstar Nano

Absorbance plate reader with cuvette port



BMG LABTECH’s innovative absorbance microplate reader has the flexibility to perform assays quickly and easily in both microplates or via the built-in cuvette port. This spectrometer-based absorbance microplate reader captures a full UV/visible spectrum in less than 1 sec/well. Its speed, simple push button operation, and capacity to store individual assay protocols make the SPECTROstar® Nano the leading microplate reader for absorbance measurements.

SPECTROstar-Nano

Ratings

select-science 11-2

Versatile, easy to use microplate reader with ...

We needed an affordable, easy to use but versatile microplate reader for our basic lab skills...
4.9/5.0 (21)
Rate
All reviews
Product details FAQs Reviews Application notes Citations Technical specifications Compare readers

SPECTROstar Nano

The SPECTROstar Nano is equipped with BMG LABTECH’s ultra-fast UV/vis spectrometer, which allows users to measure full-spectrum absorbance (220 – 1000 nm) in less than 1 second per well. It is the ideal instrument to read all absorbance assays in a microplate or cuvette – with many common assay protocols predefined and available at the click of the mouse.

The SPECTROstar Nano is for research use only.

Features



Trusted and loved by:customer-logos

Optional accessories

  • THERMOstar: microplate incubator and orbital shaker
  • LVis Plate: plate for low-volume measurements and performance testing
  • Evaluation Plate: plate for optical functionality validation

SPECTROstar Nano

spectrostar-nano-thumbnail
Our technologies

Automation

Automation is a key feature in high-throughput screening. BMG LABTECH microplate readers have been successfully integrated into various robotic systems. Small footprint, multiple robotic software interfaces and an automation-friendly plate carrier guarantee an easy integration into all leading robotic platforms. All plate readers can be controlled through ActiveX or DDE interfaces. Moreover, the ASCII data output is the most versatile in the industry and works with most LIMS and automation platforms.

Dichroic Mirror

Dichroic mirrors have significantly different reflection and transmission properties at two different wavelengths. Specifically for optic detection, they reflect or block excitation light at lower wavelengths, and transmit emission light at longer wavelengths to the detector. Used between excitation and emission filters, they increase sensitivity and decrease background noise.

Gas Vent

BMG LABTECH offers two forms of gas control on its microplate readers. The Atmospheric Control Unit (ACU) for the CLARIOstar is a unique microprocessor-controlled unit that independently regulates both CO2 and O2 inside the microplate reader. Alternatively, the Gas Vent is a positive pressure gas purge through which the internal atmosphere of the microplate reader can be replaced.

Incubation and shaking

Shaking and incubation allow users to mix the well content and easily run measurements at elevated temperatures. The incubator controls the air temperature in the measurement chamber from room temperature up to 45°C, 60°C or 65°C. BMG LABTECH microplate readers are equipped with orbital, double-orbital or linear shaking with definable intensity, duration and direction of motion. These features are available on all BMG LABTECH plate readers.

Path length correction

Absorbance measurements such as DNA quantification or protein determination detected in a microplate reader are frequently compared and/or normalized to results from a 1 cm path length cuvette. All BMG LABTECH microplate readers have the ability to perform a 1 cm path length correction thanks to an internal fitting algorithm. Using this correction, data normalization to 1 cm path is given with only one mouse click.

UV/vis spectrometer

BMG LABTECH was the first and is the only microplate reader manufacturer to equip its instruments with a UV/vis spectrometer for absorbance measurements. Similar to a monochromator, but much faster, the spectrometer will capture full-absorbance spectra from 220 to 1000 nm at a resolution of 1 nm in less than one second/well. Alternatively, up to eight discrete wavelengths can be collected at the same time.

Well-scanning

For non-homogeneous samples such as for cell-based assays, where the sample distribution is uneven across the well, a single reading in the centre of the well is inadequate. To overcome this problem, all BMG LABTECH readers come with an advanced Well Scanning feature that can take multiple measurements in each well with a resolution of up to 900 points/well. Alternatively, in spiral or orbital averaging mode, the reader takes several measurements for each well on a defined spiral or orbit and calculates an average.
